PX-Series Tube Cutting Machine
Fiber Laser Cutting Machines
/Tube/Profile Cutting
Description :
PX-Series Pipe Cutting Machine
Precision in Every Tube. Speed in Every Cut.
The HEXA PX-Series Fiber Laser Tube Cutting Machine is engineered for high-speed, high-accuracy tube and pipe cutting across a wide range of industrial applications.
Powered by a precision fiber laser source and servo-driven rotary chuck system, the PX-Series handles round, square, rectangular, and oval tubes with exceptional cutting consistency and minimal material waste.
Its automatic loading and unloading system and intelligent clamping mechanism ensure smooth production and reduced manual handling.
With advanced software integration, real-time alignment correction, and stable beam delivery, the PX-Series is built for continuous operation and repeatable accuracy — delivering perfectly finished tubes ready for fabrication or welding.
Designed and manufactured in Bangalore, India, the HEXA PX-Series combines speed, stability, and automation to help manufacturers boost productivity, reduce labor dependency, and achieve precision at scale.
Explore the HEXA PX-Series — a high-speed fiber laser tube cutting machine for round, square, and rectangular tubes. Engineered in Bangalore for precision, speed, and productivity.
Applications:
• Furniture and Architectural Tubes
• Automotive Exhausts and Frame Components
• Structural and Fabrication Tubes
• Machinery Frames and Enclosures
• Steel, Stainless Steel, and Aluminium Pipes
• General Engineering and Manufacturing
Technical Specifications:
| Model | PX6500-H1 Tiny Tube Cutting PX6500-H2 Professional PX6500-H3 PX6500-C3 Three Chuck System PX6500-C4 Four Chuck System |
| Maximum Round Tube Size(dia) | 8-120mm 20-240mm 40-350mm 20-240mm 80-660mm |
| Maximum Square Tube Size | 8*8-85*85mm 20*20-150*150mm 40*40-245*245mm 20*20-150*150mm 80*80-450*450mm |
| Power(W) | 1500/2000/3000 1500/3000/6000 3000/6000/12000/20000 3000/6000 6000/12000/20000 |
| Laser Head | BOCI |
| Laser Source | Max Photonics/IPG Photonics/Han's Laser |
| X/Y Positioning Accuracy | +/- 0.05mm/m |
